We strongly recommend that you spare parts fitted by a qualified guitar technician, electrical service engineer or your local music store.
All the information needed:
Product Type: Speakers
Peavey Part Number: 00560760
Product It Fits: ILS 1264V, ILS 1294H, ILS 1294V, Impulse 1012 8 Ohm Black, Impulse 1012 8 Ohm White, Impulse 200 White, SP112MX, SP12M, Impulse 200 8 Ohm
Sensitivity: 96.9 dB / 1W 1m
Voice Coil Cooling: na
Net Weight: 16 lbs / 7.3 kg
Throat Parameter: Standard: 2" / 50.8 mm; Optional: 1.6" / 40.6mm; Supplied with throat extension
Nominal Impedance: 8 Ohms
Minimal Impedance: 7.1 Ohms
DC Resistance: 6.8 Ohms
Power Capacity 1Khz - 20Khz: 500 Hz to 20000 Hz
Nominal Efficiency: 30%
Frequency Response: 500 Hz to 2000 Hz
Recommeded Crossover: 1000 Hz
Lowest Recommended Crossover: 500 Hz at 12 dB / Octave
Dimensions: Standard: 8.388" (213mm)D x 6.05" (154mm) H
Horn Coupling Diameter: na
Horn Coupling Threads: na
Shipping Weight: Standard: 25 lbs / 11.4 kg
Diaphragm Kit: 377380
Power - Peak: 2000W
Power - Program: 1000W
Power - Continuous: 500W
Frequency Range: 50 Hz - 3.5 kHz
Voice Coil Diameter: 4.0" / 100mm
Voice Coil Material: Aluminium ribbon wired; Plyimide-impregnated fibreglass former Nomex stiffened; OFHC copper leads
Znom (ohms): 4.000
Revc (ohms): 3.470
BL (T/M): 14.090
Vas (Litres): 66.200
Cms (uM/N): 172.500
Mms (gm): 47.900
Qms: 7.090
Qes: 0.311
Qts: 0.298
Xmax (mm): 2.300
Le (mH): 0.190
SPL (1W 1m): 96.600
No (%): 2.900
Vd (cu. in. /ml): 18.4 / 302
Pmax (Watts pgm): 1000.000
Disp (cu. In. / ml): 109 / 1797
Replacement Basket: 560770
